Dust Camera PTC-1040 Dynamic Differential Image Observer – MSJ Creative research Laboratory
Visualization of fine particles can be easily observed in combination with appropriate illumination.
Images from an ultra-compact, high-sensitivity, high-resolution monochrome CCD camera are processed with 10-bit (1024 gradations) high gradation for real-time differential processing.
The differential image effect enables identification of scratches and faint contrasts that are normally difficult to distinguish.
The camera, lens, and processing function board are integrated into one small unit measuring 90 x 140 x 40. The light weight (300g) makes it easy to carry and observe.
Report Abuse
Connection is simply made by connecting the AC adapter and video cable to the video terminal on the TV.
The switch on the back of the unit allows you to select between a standard image without differential processing and a differential processed image. The image can also be stilled.
Data can be easily saved to a video recorder or PC as shown in the figure above.
For Glossmeters, Laser Scanners, Printing Still Image Equipment, and Image Measurement Systems, leave it to MSJ Soken!
Business Policy
To develop and integrate sensor technology, electronic technology, mechatronics, optronics, and software technology to realize imaging, processing, and measurement in each of these areas, and to commercialize products that meet user needs and improve the level of contract development products.
Supplier Information
- Store Name: MSJ Creative research Laboratory
- Vendor: MSJ Creative research Laboratory
- Address: 242-0001
Kanagawa Yamato-shi Shimotsuruma
- Other Physical Measuring Instruments, Physical Measuring Instruments, Testing Instrument & Equipment
In-Line Non-Contact Gloss Tester GLS-2060 – MSJ Creative research Laboratory
Other Physical Measuring Instruments, Physical Measuring Instruments, Testing Instrument & EquipmentIn-Line Non-Contact Gloss Tester GLS-2060 – MSJ Creative research Laboratory
Non-contact, real-time measurement and display of change data over time.
As a gloss meter, it can quickly monitor the condition of the production line. All measurement data obtained as a gloss meter are saved for later detailed evaluation and study.
SKU: n/a - Image Sensor, Industrial Machinery, Sensor
High Resolution Printed Still Image Device Image Checker DST-2500 – MSJ Creative research Laboratory
Image Sensor, Industrial Machinery, SensorHigh Resolution Printed Still Image Device Image Checker DST-2500 – MSJ Creative research Laboratory
The Image Checker DST-2500 monitors register marks, halftone dots, color tone, missing barcodes, and other print quality in gravure, form, label, and flexographic printing with high-quality still images.
Automatic monitoring of register misalignment
Automatic detection and alarm of misalignment beyond a set value.High-definition image display
High-density images of 1392 (width) × 1040 (height) are more than four times higher in quality than conventional models.SKU: n/a - Industrial Laser Equipment, Industrial Machinery, Laser Scanner
Curved Surface R・Step・Gap Measuring Instrument R・D・G Gun2 – MSJ Creative research Laboratory
Industrial Laser Equipment, Industrial Machinery, Laser ScannerCurved Surface R・Step・Gap Measuring Instrument R・D・G Gun2 – MSJ Creative research Laboratory
Analog Caliper This is a high-function DX measuring instrument that replaces the analog caliper gauge.
It contributes to efficiency in the inspection process of many products in the automotive industry, home appliances, metal and plastic products, etc.
SKU: n/a - Industrial Laser Equipment, Industrial Machinery, Laser Scanner
Real-time 3D profiler LHS-IV – MSJ Creative research Laboratory
Industrial Laser Equipment, Industrial Machinery, Laser ScannerReal-time 3D profiler LHS-IV – MSJ Creative research Laboratory
The cross sectional shape of a workpiece can be observed in real time by holding it with one hand.
Compact, lightweight, handy operation: L-shaped, 2 kg, built-in camera and laser control circuit, and connection to PC with a single USB cable.
3D scanning: Surface and full-surrounding geometry can be easily measured and displayed by using a 1-axis moving stage and a rotating stage.
Measurement data can be immediately observed with K3D VIEWER, displayed in EXCEL by saving CSV, or output externally by ASCII code.
Compact configuration that can be operated with a notebook PC.
Easy to use and low price by thorough VE.
Three standard variations (L, M, S) are available.
We will promptly respond to special orders and requests. Laser emission wavelength can be changed to blue, green, IR, etc. From 10mm to 2000mm size, for hot profile measurement at 1000℃. For measurement of micro warps, bumps, and steps, etc.
Examples of applications: Rail wear measurement system, wheel wear measurement, high-temperature large-diameter forged disc dimensional inspection system, tile alignment inspection system, etc.
SKU: n/a
