packaging machine FIT-S – Nippon Technology Solution Co. Ltd.

Compare

Shrink beautifully when combined with TORNADO!

Manual L-shaped wrapping machine FIT-S is ideal for high-mix low-volume production. Compact and space-saving. Thermal whirlwind shrink wrapping machine

Report Abuse

Product Features

Supports Curved Cutting
Compatible with curve cuts
Suppresses the generation of horns.

High-mix low-volume production
High-mix low-volume production
Ideal for those looking for high-mix low-volume production.

Operation Procedure

  • Step 1
    Set the product in the film.
  • Step 2
    Slide the film horizontally
  • Step 3
    Gushan! and the process is complete. Even women can operate it easily.

Specifications

Power supply 100 V　50 Hz/60 Hz
Power consumption 1.2 kW
Sealing method Fusion seal
Seal dimensions Seal dimensions 400 mm (W) x 350 mm (D)
Heating temperature 90 ℃～ 200 ℃ (accuracy: ±15 °C of set temperature)
Applicable film dimensions Maximum roll width 400 mm (Maximum roll diameter 190 mm)
Table height adjustment Motor-driven stepless adjustment (elevation stroke 50 mm)
Operating temperature and humidity range Operating temperature and humidity range +5 to 40 °C (30 to 80 % RH)
Machine dimensions 800 mm (width) x 600 mm (depth) x 715 mm (height) (430 mm when lever is closed)
Weight Approx. 45 kg
Outline Drawing 外形図



VIDEO
