TMP-S301Au ROHS – TOPURAHANBAI.CO.LTD

Compare

Plug shape: φ3.5mm-4-pole jack (female, gold flash plating)

Contact (electrode) material: Copper alloy + gold plating and nickel plating
Grip: Electroless nickel platingGrip diameter: φ10mm (±0.2mm) Grip length: 29mm (±0.5mm)
Compatible cable diameter: up to φ5.0mm (+0-0.2mm) I’m here.

Features

  • It is a highly reliable in-line jack that boasts excellent durability in plug insertion/removal evaluation tests.
  • Unlike the standard brass (copper purity ≈ 60%), the contact material uses a spring material with a copper purity of 93% and low conductor efficiency, resulting in excellent contact characteristics.
  • By applying our unique manufacturing technology, we have achieved excellent performance in terms of “workability and various characteristics”, and it is a product with excellent cost performance.
  • The plating surface treatment of the terminal and the durability strength are also very high.
  • It is a specification related to surface plating and body plating.
  • Working condition of terminal temperature: about 250 degrees/2.5 seconds
