TE-9040B5P5S (N) – Electromagnetic buzzer / Magnetic buzzer – TECHTUIT CO. LTD.


Non-washable type (Dip solder impossible) Pin connection

Pin connection type
RoHS compliant

Report Abuse

Examples of Uses

Housing remote controls, measuring equipment, home appliances, security equipment, control devices, etc.

Spec

Part number : TE-9040B5P5S (N)
External dimensions(Mm) : Φ 9.0 * 4.0 t
Rated voltage(V) : 3.6
Reference frequency(Hz) : 2,731
Sound pressure (dB),Min. (10 cm) : 88
The average current consumption,Max. (MA) : 70

Frequency characteristic

Recommended land pattern
