Standard Connectors 220WP SERIES – Witco of Jupiter Dentsu Co. Ltd.

Compare

16-pole, 1A, one-touch lock connector with 12.4 mm (OD) plug and 12 mm (OD) receptacle.

Relaying type also available. Waterproof rating IP67.

Features

Waterproofness Locking method
Waterproof(IP67) One-touch lock
Current capacity Number of poles
1A 16

Compatible cable diameter

φ5.0 / φ6.0

External dimensions may vary depending on the compatible cable diameter.

Coupling surface (female)

External dimensions(mm)

Specification

16-conductor, fully shielded cable
Core wire AWG28
Shield type horizontal winding
Outer diameter(mm) φ6.0
Withstand voltage AC500V/1minute
Insulation resistance 5MΩ・km
Conductor resistance 228Ω/km
Type TZ-937
Red/White/Blue/Black/Green/Orange/Purple/Yellow/Gray/Brown (White/Black)/(White/Red)/(White/Yellow) (White/Blue)/(White/Purple)/(White/Green)
