No.169 Manual Water Proof Tester – YASUDA SEIKI SEISAKUSHO LTD.
Water Proof Test of rubber・plastic cloth
Manual water resistance tester is a testing machine (water resistance tester) that performs water resistance testing of rubber and plastic pultruded fabrics. It corresponds to test method B. The specifications of the manual water resistance tester are as follows.
Features
- This machine is manufactured in accordance with the above standards.
- This tester (water resistance tester) is used to test waterproofing of rubber/plasticized pultruded fabrics.
- It corresponds to test method B.
- It also complies with method B (high water pressure method) of water resistance test (hydrostatic pressure method) for textile products.
- The test specimen is mounted so that water pressure is applied to it, and then it is held down by a plate with 45 small holes of 3 mm in diameter.
- After applying the specified water pressure, the test specimen is left for 1 minute to check for leakage or other abnormalities.
Specifications
| Specimen | 150 × 150 mm |
| Clamp | Inner φ100 mm |
| Pressure Gauge | Max. 0.3 MPa (Scale 0.002 MPa) or 0.6 MPa (Scale 0.005 MPa) |
| Perforated Plate | φ140 mm, Spot φ3 mm: 45 pcs |
| Dimensions/ Weight (Approx.) | W440 × D480 × H800 mm, 37 kg |
YASUDA SEIKI is pleased to contribute our original testing machines for your products’ quality control, research and development.
Designing and producing material testing machines which meet global standard methods such as JIS, ASTM, and ISO. Researching and improving the quality of testing machines, supplying, and maintaining testing machines are one of our Business also.
