Low-Profile Hybrid FPC-to-Board Connector Supporting 5A BK13C06-12DP/2-0.35V(895) – Hirose Electric Co. Ltd.


0.35mm Pitch, 0.6mm Stacking Height, 1.9mm Width,Low-Profile Hybrid FPC-to-Board Connector Supporting 5A

Low-Profile Hybrid FPC-to-Board Connector Supporting 5A

Report Abuse

Features

Hybrid Power Supply Capacity and Space-saving Design

Equipped with two power contacts capable of
handling up to 5A, reducing the number of signal
contacts to save mounting space.

Robust Design

Fully armored guides prevent housing damage
due to misalignment when mating.

Enhanced PCB Peeling Strength

Both the geader and receptacle have 3 soldering
areas at each power contact for greater PCB peeling
strength.

High Contact Reliability

Both power and signal contacts have a two-point
contact design, ensuring high contact reliability.

Superior Mating

Wide self-alignment range with metal guides offers
enhanced mating operation.
(0.3mm in pitch direction, 0.22mm in width
direction)
Additionally, a clear tactile click generated by the
unique locking contact design secures complete
mating.

Halogen-Free

All materials and substances used to produce this
product Comply with Halogen-free standards.
*As defined by IEC 61249-2-21
Br : 900ppm max., Cl : 900ppm max.,
Br+Cl : 1,500ppm max.

Specializes in the manufacture and sale of multi-pole connectors and coaxial connectors, which include circular connectors as well as connectors designed for printed circuit boards.

Hirose Electric Co.,LTD. specializes in the manufacturing and distribution of connectors, with a focus on multi-pole connectors and coaxial connectors. Their range of multi-pole connectors includes circular, rectangular, and printed circuit board connectors, which are manufactured and sold by their subsidiaries in Japan and other countries. Their coaxial connector line is manufactured and sold by domestic and overseas subsidiaries, including optical connectors. Additionally, they also produce and distribute micro switches. To expand their global sales network and production capabilities, the company has established subsidiaries in various regions, including Europe (such as the Netherlands), the United States, and East to Southeast Asia (such as China and Singapore).

HRS MANAGEMENT PRINCIPLES

Hirose will connect wisdom by thinking small, create new value, and contribute to the development of a global society.

“The principle of ‘being small’” represents our aspiration that we should always consider ourselves small and remain a company with great potential. On the other hand, “connecting wisdom” represents our desire to absorb external knowledge and wisdom with honesty and humility, translate them into excellent original products by connecting them with our own internal knowledge and wisdom, and then provide such products to the world. In this way, we intend to produce even greater results as a means of realizing the aspiration described above.

With these basic principles, we aim to develop, manufacture, and distribute excellent connectors that can, with their “connecting” function, bring different parts and products — which are themselves crystallizations of people’s wisdom — together, produce various new products, and contribute to the development of a global society.

Need more info ?

BK13 Series Catalog

Hirose Electric Co., Ltd.

View Catalog

Supplier Information

  • Store Name: Hirose Electric Co., Ltd.
  • Vendor: Hirose Electric Co., Ltd.
  • Address: Kanagawa Yokohama 2-6-3 Nakagawa Chuo, Tsuzuki-ku
