High Power Laser Machine RSD-SUNMAX-FL1325LC
, ,

High Power Laser Machine RSD-SUNMAX-FL1325LC – RSD Co. Ltd

Compare

This is a completely new laser machine that combines a “”fiber laser”” and a “”CO2 laser””.

FL1325LC is a model with a fiber laser source and a C02 laser tube in one machine. Two machine duals are used that are suitable for non-ferrous and non-ferrous materials. The use of two dual machines suitable for different materials eliminates the need for separate laser processing machines for different materials, thus saving space and increasing efficiency.
The CO2 laser can process materials such as fabrics, wood, veneer, acrylics, paper, etc., and the fiber laser can process stainless steel, carbon steel, alloy steel, copper, brass, etc.

Specifications

Model RSD-SUNMAX-FL1325LC
Dimensions [mm] 3800 X 1850 X 1300 (Main Unit)
1300 x 800 x 800 (External Laser Box)
Laser Type Fiber Laser + CO2 Laser
(IPG or Raycus or RECI oscillator)
High Reflective Material for Fiber Laser Yes
Laser Output Fiber Laser: 1000 / 1500 / 2000 W
CO2 Laser: 150W
RECI: 1500W～
Wavelength Fiber: 1090nm, CO2: 10600nm
Processing Area [mm] 2500 X 1300
Max Cut Thickness [mm] Up to 6 (Steel plate)
(When using a 500W Fiber Laser)
Work Area Size [X x Y x Z mm] 2525 x 1325 x 100
Max Speed [m/min] 20
Voltage AC220V/50Hz/60Hz/60A
Power Consumption [KW] Standby: 0.2, Processing: 2.8
(IPG 1000W Laser Unit)
Power Factor [%] Standby: 58, Processing: 99
(IPG 1000W Laser Unit)
Operating Power Consumption [KW] 6.3 (Main unit + Water cooler + Exhaust fan)
(IPG 1000W Laser Unit)
Import File Formats DXF, PLT, AI, Gerber, NC (G-code)
Follow (Imitation Sensor) Automatic calibration available
Positioning Accuracy [mm] ±0.03
Plotter Drive Ball screw
Control Unit Command Unit: 0.001mm or less
Command Method: G-code/M-code
Program Transfer Method: USB
*Internet connection is prohibited
Operating Device Color 10.4 inches or more.
Keyboard, Mouse, Remote Control
Touch panel is optional
Included Jet Nozzles Single and double jet nozzles in the following sizes:
Φ0.8, Φ1.0, Φ1.2, Φ1.5, Φ1.8, Φ2.0, Φ2.5, Φ3.0
Auto Focus Yes
Dynamic adjustment of focal distance during processing, effective when working with different materials.
*Optional for 1000W machines, available for all models.
If there is no auto focus, manual adjustment of the focal distance is required based on the material being processed.
Collision Avoidance Yes
Function to avoid obstacles such as remaining processed material in a tilted state after cutting, allowing continuous processing.
*Optional, available for all models.
FL1325LC Packaging Box Dimensions [mm] 4150 x 2300 x 2010
(Approximate ±20mm error for individual units)
Transformer Dimensions [mm] 580 x 380 x 750
IPG Power Supply Dimensions [mm] 990 x 600 x 570
External Laser Box Dimensions [mm] 1300 x 800 x 800
Automatic Water Cooler Dimensions [mm] 440 x 700 x 950
Operating Temperature [℃] 0 ～ 40
Processable Materials Stainless steel, carbon steel, alloy steel, copper, brass, silicon steel, galvanized steel plate, nickel titanium alloy, Inconel, titanium alloy, and other metal materials.
Installation Space Requirements A minimum clearance of 1.5m or more is required on all sides in relation to the main unit dimensions
Options (excluding tax)
  • 1500W and above come with standard auto-focus. For 1000W below, auto-focus is optional. Pre-application is required for auto-focus under 1000W.
  • Servo motors are standard inovance. Optionally, change to Yaskawa motors.
  • Collision avoidance cutting function (Avoidance of laser head contact) can be upgraded as an option (Quotation required).

Main components included in the product

laserhead01

Medium and small fiber lasers.

Optical parts are resistant to dust adhesion.
It has a cam structure for accurate focus adjustment.
The drawer has a protective lens for easy replacement.

au3tech system

The perfect solution for all kinds of encryption problems.
Extensive fiber laser cutting processes and parameters improve the quality of the cutting effect.

monitor01
w-temp01

Double control with two thermometers

Two water temperature displays and two water pressure gauges provide cooling of the laser source and laser head.

Laser Light Source

The IPG laser source can operate for 100000 hours.
It is cost-effective and more stable.

ipg01
auto-higher01

Automatic surface tracking function

The system is equipped with a function that automatically adjusts the distance of the processed surface according to the height of the plate, allowing for more precise finishing.

Servo Motor

High-precision servo motors provide powerful output and high-speed operation.
Stable torque has low inertia and smooth rotation.
High efficiency and low operating temperatures prevent high operating temperatures.

motor01
reducer01

Reducer

Efficiently increases the output of the servo motor and also reduces the load on inertia to increase processing speed.

Composition

Au3tech head & controller, TBI ball screw, HIWIN guide linear, Delta servo, AIRTECH pneumatic components. Computer and arm controller not required, RECI CO2 150W

Machining Samples

Processing Sample Video
