“1mm Band ASE-Free Tunable Diode Laser”

Our wavelength tunable lasers use our proprietary transposed Littman-type external resonator structure to completely separate the ASE from the output optical axis without sacrificing optical output intensity, achieving both high output intensity and high spectral purity (ASE-free). In addition, the Littman configuration, which is a geometrically and mathematically ideal configuration, is partially deformed to compensate for the dispersion of the LD chip and optics to achieve mode hop-free tuning over a wide wavelength bandwidth even in the 1um band, where chip dispersion becomes apparent, let alone in the communication band. To fully use the performance of the external cavity, a stepper motor type pressure contact slider with backlash-free and ultra-precise motion is used as the wavelength tuning actuator to achieve wavelength sweep performance that contributes to precision spectroscopic measurement. Other features include an analog wavelength sweep function using PZT, an auto-focus function for fiber couplings that takes advantage of high output power, and a data acquisition function synchronized to wavelength tuning, all of which can be fully utilized by the spectroscopic measurement software to meet the high demands of laboratory users. The software is available in executable file format, and LabVIEW source code is also distributed.

Features

  • ASE-Free Output : ＜-80dB＠0.01nm
  • High Output Power : ＞100mW (Free), 50mW (Fiber)
  • Wide Tuning Range : ＞100nm (980~1090nm)
  • Mode Hop Free Tuning : ＞50nm
  • Narrow Linewidth : ～100kHz (10 μs)
  • Digital Control : 0.1pm /step res.
  • Built-in Data Acquisition : 16bit – 2ch.
  • PC Control : LabVIEW software

Related Data

ASE-Free Spectra

Free Space and Fiber Output

Control Software

Specifications

Specifications l-Master 1040 Comments
Tuning Range 980~1090nm 920~1000nm is also available
Mode Hop-Free Tuning >50nm around specified wavelength
ASE-Free Output Power >100mW @1040nm SMSR:>[email protected]
Fiber Coupled Power >50mW @ 1040nm Optional
Max. Tuning Resolution 0.1pm (30MHz) Digital control by stepping motor
Max. Tuning Speed 30nm/s Any speed between 1~300000pps
Linewidth (1ms) <100kHz In silent environments
Current Modulation ~45MHz/mA Bandwidth: <100kHz
PZT Continuous Tuning >100GHz Optional
Built-in Etalon Monitor 10GHz Etalon Optional
Rapid Data Acquisition 16bit 2 ch. Analog Input Synchronized to control pulse
System Control LabVIEW Software USB bus, DI and DO for step scan
Laser Head Dimension 110x166x330mm, 5kg Controller : 240x140x360mm, 6.5k

*Specification may change without notification.
