3D X-ray CT System XVA-160RZ – U.H.SYSTEM
High resolution Wide field
This is a standard model that allows you to choose between a high-resolution type and a wide-field type.
Standard Specifications
- Flat panel detector
- Eucentric function
- High magnification(1,600x)
- Visible light mapping function
- Automatic focus adjustment function
Optional Features
- 3D oblique CT function
- Orthogonal CT Unit : Presto
Use Case
This is an example of using the ３D oblique CT function of the MicroFocus X-ray CT system XVA-160RZ to separate voids from MOSFET solder mounting and voids from the paste under the chip inside the package.
Ultra-high-resolution X-ray CT from Japan.
We are a Japanese company developing high-end X-ray and CT system solutions that enable non-destructive testing in the semiconductor/electronics, automotive, and industrial sectors. Our Nano-Focus X-ray CT system achieves industry-leading magnification and high resolution.
Need more info ?
XVA-160RZ High resolution 3D X-ray CT system
U.H.SYSTEM
Vendor Information
- Store Name: U.H.SYSTEM
- Vendor: U.H.SYSTEM
-
Address:
242-0001
Kanagawa Yamato-shi 505-1 Shimotsuruma
