20A Current, Compact, Waterproof Power/Signal Hybrid Connector BH12-P-213 – Hirose Electric Co. Ltd.


The BH12 Series is a power/signal hybrid connector ideal for the battery connection of micro-mobility applications.BH12 can also be used in other industrial applications as well. The BH12 Series is an IPX6/IPX7 waterproof connector(when mated) with lock lever design and enhances cable wiring efficiency. Additionally, the power/signal hybrid designcontributes to reducing connector occupied mounting space.

20A Current, Compact, Waterproof Power/Signal Hybrid Connector

Report Abuse

1.Compact connector with φ 13.8 diameter that supports high current up to 20A.

Although the total length is 36mm and the diameter is φ13.8mm,

BH12 is compatible with 14 AWG size cables and enables a high current of 20A.
Plug Outer Diameter : φ13.8
Maximum Outer Diameter : φ15.8
Mounting Dimensions
Front Mount Type : 23.1mm
Rear Mount Type : 13.6mm
(When using a 6mm panel)



2.The hybrid power/signal design enables application size reduction.

Connector occupied mounting space is reduced by combining power and signal.

Supports Power 20Ax2pos., Signal 1Ax2pos. (or Signal 1Ax1pos.)

3.Waterproof Design

IPX6/IPX7 Waterproof Performance in the Mated State
IPX6 : Jet water of 100 L / min. in all directions from a distance of
3 m for 3 minutes in mated condition.
IPX7 : At a depth of 1m for 30 min.
(IPX8 class is also available)



4.Lever lock for easy wiring.

The lock lever is locked in one action: simply push the plug straight into the receptacle.

The lock lever on both sides of the plug prevents cable entanglement, lock deformation and damage during cable assembly and transportation.



5. Easy cable assembly

The plug side utilizes Hirose’s original design of inserting the contacts to the case from the side.

It can be used with an overall short cable assembly length and no tools are required.



6. Mis-mating Prevention

Multiple guide keys for secure alignment and mating even in areas with poor visibility.

7. Light weight

The lightweight of 7g (plug+receptacle)
contributes to equipment weight reduction as well as reduced power consumption of micro-mobility applications.

8. Both front and rear mount available

The receptacle is available in both front and rear mount types for selection based on the usage conditions.

The front mount type is effective for reducing space used inside the panel.

With the rear mount type, pre-assembled cable assemblies can be attached to the panel.

Additionally, screws are not visible from the panel exterior.

9. Height inside panel is reduced by connecting the power contacts at a right angle.

The power contacts on the receptacle side are soldered at a right angle, contributing to height reduction inside the panel.
